22kW OCPP WiFi RFID 3-Phase EV Wallbox — Commercial-Grade Level 2 EVSE
A professional 22kW wallbox with full OCPP 1.6J protocol support for commercial charging networks. Triple authentication via RFID, WiFi APP, and plug-and-charge. 3-phase 32A delivers maximum Level 2 AC charging speed for compatible electric vehicles.
Key Features
- ⚡ 22kW 3-Phase Ultra-Fast — 32A at 400V for maximum AC charging speed on compatible EVs
- 🌐 OCPP 1.6J Protocol — Full commercial charging network integration and remote management
- 🔐 Triple Authentication — RFID card + WiFi APP + plug-and-charge for flexible access control
- 📱 Smart APP & Cloud Platform — Remote monitoring, revenue management, and firmware OTA updates
- 🖥️ LCD Color Display — Bright screen with charging data, QR code payment, and status info
- 🛡️ Commercial-Grade Safety — PEN fault, 6mA DC leakage, overcurrent, surge, ground monitoring
- ⚖️ Dynamic Load Management — Multi-charger load balancing for parking lot installations
- 🌊 IP65 + IK10 — Weatherproof and vandal-resistant for public charging locations
- 💰 Revenue-Grade Metering — Built-in MID-certified meter for accurate billing
- 🔌 Type 2 Socket or Tethered Cable — Flexible configuration for different installation needs
Specifications
- Max Power: 22kW (32A @ 400V 3-Phase)
- Connector: Type 2 Socket or 5m Tethered Cable
- Protocol: OCPP 1.6J ( upgradable to 2.0.1)
- Authentication: RFID (MIFARE/ISO 14443) + APP
- Communication: WiFi + Ethernet + 4G (optional)
- Display: 4.3″ LCD Color Screen
- Protection: IP65 / IK10
- Metering: MID Certified ±1%
- Operating Temp: -30°C ~ 55°C
- Certifications: CE, TUV, UKCA, OCPP Certified
Perfect For
Commercial parking facilities, workplace charging networks, fleet depots, hotel and retail EV charging, multi-unit residential buildings, and public charging operators. Full OCPP integration with major CPMS platforms.
